EBS Stanley Clarke

EBS Stanley Clarke Signature Acoustic Preamp. Precision-crafted for upright bass and beyond.

Co-designed with bass legend Stanley Clarke, this 2-channel preamp delivers studio-quality tone, unmatched filtering, and smart flexibility for acoustic instruments—especially upright bass. Runs at console-level for superior headroom and clarity, optimized to handle the complex tone of upright bass Built with premium components for maximum fidelity.


Independent eq with sweepable mids, bass & treble, includinhg switchable High-Pass or notch filter per channel for feedback control. Blend or toggle channels—ideal for mixing pizzicato and arco styles Works with passive, active, and piezo pickups (10 MΩ impedance). Channel A supports Electret pickups; Channel B accepts 48V phantom-powered mics or ¼″ inputs. Phase Inverter on Channel A to address blending phase issues. XLR out with speaker sim, ground lift, and FOH-ready signal, effects loop, tuner out, aux in, and pro-grade headphone out.



Features
check_circle_outline
2-channel analog preamp (A/B or A+B)
check_circle_outline
Operates with Studio-grade signal quality
check_circle_outline
10 Mohm Impedance inputs (both channels)
check_circle_outline
Individual High Pass/Notch Filter for each channel
check_circle_outline
XLR microphone-input with Phantom Power (channel B)
check_circle_outline
Electret pickup support (channel A)
check_circle_outline
tuner Output
check_circle_outline
Effects Loop (serial/parallel)
check_circle_outline
Balanced Output with Speaker Simulator and Ground Lift
check_circle_outline
Aux Input and professional-grade headphones output
check_circle_outline
Dedicated 9V DC Power Supply included
Specifications
EBS Stanley Clarke Pre Amp Bass Pedal
Miscellaneous
Channel Specifications: Input Impedance
10 Mohms, 22 pF
Gain
Gain Range -∞ / +30 dB, Gain Peak LED (ch A = RED, B = yellow) +10 dBv, Frequency Response +0 / -3 dB 20 – 20,000 Hz
Bass Filter
Type Shelving, Gain Range +/- 15 dB @ 40 Hz
Mid Filter
Type Bandpass Filter, Gain Range +/- 13 dB, Frequency Range 70 – 2,500 Hz, Q 0.8
Treble Filter
Type Shelving, Gain Range +/- 15 dB @ 10 kHz
HP filter
Type 12 dB/octave High Pass, Frequency Range 20 (off) – 450 Hz
Notch Filter
Type Bandpass Notch, Frequency Range 70 – 2,200 Hz, Q 7, Attenuation 7 dB (typically)
Electret Power (Channel A)
5V, 2mA
Common Features: Effects Loop
Loop Signal Level -10 dBv (nominal), Gain Unity (1:1), Output Impedance 2 kohms, Input Impedance 100 kohms, Modes Serial or Parallel
Phones Out
Recommended Impedance 32 – 200 ohms
Entrada auxiliar que permite ligar um dispositivo áudio ao equipamento.
AUX Input
Input Impedance 20 kohms, Nominal Level -10 dBv
Output(s)
Output Impedance 1 kohms, Signal Level 0 dBv (nominal)
É um método de interligação de equipamento de áudio que utiliza linhas equilibradas. Este tipo de ligação é muito importante na gravação e produção de som porque permite a utilização de cabos longos ao mesmo tempo que reduz a susceptibilidade ao ruído ext
Balanced Output
Output Level -20 dBv (nominal), XLR Connections 1-GND, 2-Hot, 3-Cold, Options Gnd Lift, SPKR Sim
Balanced Input (Channel B)
Input Level -30 dBv (nominal), XLR Connections 1-GND, 2-Hot, 3-Cold, 48V Phantom Yes
Auxiliary Info
Power Requirements Idle 500mA @ 9V, Max 800mA @ 9V (with headphones at max output level)
Dimensões totais do equipamento, especificadas em milímetros.
Dimensions (WxDxH)
max 168 x 124 x 53 mm / 6.6″ x 4.9″ x 2.1″
Item weight. Usually given in Kg (or Pounds). Sometimes also other types of indications, such as for drum cymbals, for example.
Weight
660 g (1.5 lbs.)
